4 M KIT FOR THE NORTHLAKE 900R ROD
Store Availability
Store availability
BENEFITS
Compatibility
The 4 kits are compatible with the NORTHLAKE -900R rod
Easy assembly / dismantling
The internal Teflon bush mounted on the tip allows for quick operation
Glide performance
ANTI-FRICTION SYSTEM AFS to glide more smoothly between your hands
Rigidity
FUSION technology on the tip and 55/80T HM carbon over the length of the kit.
Robustness
Power kit with external elastic threader for fishing fine cyprinids
Impact protection
CLEAN CAP SYSTEM CCS to protect the components subject to the greatest stress
User comfort
Components 2, 3 and 4 with TEFLON TJ fittings for greater comfort
Repair
All the rod components can be ordered in store or via our website
TECHNICAL INFORMATIONS
TECHNICAL FEATURES KIT 4M CLASSIC / Fishing for white fish weighing up to 2 kg
Composition: High-modulus carbon 55 and 80 tonnes
No. of components: 3
Weight: 89 g
4 m length
Internal tip diameter: 2 mm (internal cavity measurement of the pre-fitted Teflon bush)
External tip diameter: 5.00 mm
Internal diameter of PTFE bush: 2 mm
Monobloc tip length: 1.33 m
Tip with FUSION technology for increased rigidity
TEFLON JOINT JT on components 2 and 3 for a better glide and increased longevity
Storage dimensions: 143 cm
Protective PVC tube
TECHNICAL FEATURES KIT 5.6 M CLASSIC / Fishing for white fish weighing up to 2 kg
Composition: High-modulus carbon 55 and 80 tonnes
No. of components: 4
Weight: 174 g
5.6 m length
Internal tip diameter: 2 mm (internal cavity measurement of the pre-fitted Teflon bush)
External tip diameter: 5.00 mm
Internal diameter of PTFE bush: 2 mm
Monobloc tip length: 1.33 m
Tip with FUSION technology for increased rigidity
TEFLON JOINT JT on components 2, 3 and 4 for a better glide and increased longevity
Storage dimensions: 160cm
Protective PVC tube
TECHNICAL FEATURES KIT 4 M LIGHT / Fishing for white fish weighing up to 1 kg
Composition: Japanese high-modulus carbon, which provides high rigidity and better balance.
Number of components: 3
Weight: 86 g
Length 4 m
Internal tip diameter: 2 mm (internal cavity measurement of the pre-fitted Teflon bush)
External tip diameter: 5.00 mm
Internal diameter of PTFE bush: 2 mm
Monobloc tip length: 1.33 m
8604196 SERV. NORTHLAKE-900 R ELT1 TIP
8737838 SERV. NORTHLAKE -900 R LIGHT ELT2
8732897 SERV. NORTHLAKE -900 R LIGHT ELT3
TECHNICAL FEATURES KIT 4 M POWER / Fishing for white fish weighing up to 5 kg
Composition: High-modulus carbon 55 and 80 tonnes
No. of components: 3
Weight: 102 g
4 m length
External elastic threader made from Teflon with a 2 mm slot
Reinforcement on the lower 50 cm of component 2 for a better hold
Internal tip diameter: 2.3 mm (internal cavity measurement of the pre-fitted Teflon bush)
Tip-end diameter of bush: 2.5mm
Internal diameter of PTFE bush: 2.3 mm
Monobloc tip length: 1.33 m
Tip with FUSION technology for increased rigidity
Storage dimensions: 143 cm
PVC tube
PRECAUTIONS FOR USE
This rod is designed for fishing cyprinids, so the thickness of the carbon has been reduced on components 4, 5 and 6 for a more lightweight design.
This also means that these components are more fragile, hence the importance of using extra butt sections specific to medium-distance fishing which will give you something more substantial.
8615816 EXTENSION NORTHLAKE-900 R 0.5 m 7 m / 8.8 m
8615815 EXTENSION NORTHLAKE-900 R 0.5 m 4 m / 5.6 m
The same is true for fishing with a baiting arm
AFTER-SALES SERVICE / SPARE PARTS
Available to order. Two-year guarantee:
8604196 AFTER-SALES SERVICE: TIP NORTHLAKE-900 R ELT1
8604195 AFTER-SALES SERVICE: NORTHLAKE-900 R ELT2
8604194 AFTER-SALES SERVICE: NORTHLAKE-900 R ELT3 & POWER
8604193 AFTER-SALES SERVICE: NORTHLAKE-900 R ELT4
8642408 AFTER-SALES SERVICE: TIP NORTHLAKE-900 R POWER ELT1
8642407 AFTER-SALES SERVICE: NORTHLAKE-900 R POWER ELT
As component 3 is the most used, we have intentionally opted for a reinforced component compatible with all kits.
SPECIFIC TECHNICAL FEATURE
Rod designed in collaboration with the Italian manufacturer Reglass, incorporating special concepts such as :
TEFLON JOINT JT on components 2, 3 and 4 – those subject to the most intensive use when fishing – for a better glide and increased longevity.
FUSION technology on the tip for greater rigidity, and therefore greater precision when fishing.
ADDITIONAL TECHNICAL FEATURES
The CLEAN CAP SYSTEM is a protective cone made from EVA stuck to the upper part of components 2, 3 and 4 for cleaning the internal fitting of the lower component as well as helping to protect both components from knocks when being fitted together.
ANTI-FRICTION SYSTEM to glide more smoothly between your hands when fishing.
COMPOSITION
composition
Metallic structure: 100.0% Carbon Fiber
Tips for storage and maintenance
Storage tips
Take care to keep your kits in the protective tubes as well as a suitable rod bag to protect them from knocks.
Restrictions on use
Do not use near power lines or during thunderstorms.
TESTS AND WARRANTY
Test product
TEAM CAPERLAN's engineers and designers have developed this rod in Cestas, south-west France.
Warranty
2 Years
Agree by
Tests were carried out at numerous fishing spots in France in 2020 to confirm that the product fulfilled anglers' needs for competitive fishing with press-fit rods. Nicolas from DECATHLON in Auxerre, Ludovic from DECATHLON in Chalon-sur-Saône, and Aurélien from DECATHLON in Petite Forêt were an integral part of this year-long testing process.
